70
4.4.3
ChipProg Device Programmers
for setting custom values for Vcc and Vpp voltages.
Buffer Dump Window
The Buffer Dump window displays the contents of the
ChipProg supports a flexible buffer structure:
You can create an unlimited number of buffers. The number of buffers that you can open is
limited only by the available computer RAM.
Every buffer has a certain number of sub-levels depending on the type of target device. Each
sub-level is associated with a specific section of a target device's address space. For
example, for the Microchip PIC16F84 microcontroller every buffer has three sub-levels: 1)
code memory; 2) EEPROM data memory; 3) user's identification sub-level.
This flexible structure allows for easy manipulation of several data arrays that are mapped to different
buffers. To open a Buffer Dump window , click on the command Main Menu > View > Buffer Dump .
The picture above displays three Buffer Dump windows representing three parts of the same buffer:
#1 (the largest) shows the buffer contents beginning at address 0h;
#2 shows the same buffer contents beginning at the same address but displaying data in decimal
format;
#3 window shows the data beginning at address 200h.
The left-most column in the windows above shows absolute addresses of the first cell in a row. The
addresses always increment by one byte: 0, 1, 2…. Each address is followed by a semicolon (:).
When you resize the window it automatically changes the addresses shown in the address column
in accordance with the number of codes or data that go in one line. Some windows may be split into
two panes – left pane for data in a selected format and right pane showing the same data in ASCII
? 2010 Phyton, Inc. Microsystems and Development Tools
